INMILL 35 freesmachine
Merk : Intos
Type : INMILL 35
X / Y / Z - 450 / 350 / 400 mm
Productomschrijving
DESCRIPTION:
With the model INMILL 35, successor of our successful milling machine FNGJ 30, we address primarily the customers oriented to production. This machine is characterized by high cutting power, maximum accuracy and universality of the utilization. Bigly dimensioned area enables machining up to work piece’s weight of 600 kg. The ample accessories ensure the easy solution of the problems connected with machining. The INMILL 35 machine is equipped with the ball screw and linear lines for accurate adjustment of axes and for faster working.
- Rotary control panel
- Pulsed operation of master and feed works
- Right-handed / left-handed master spindle
- All the compressive components can be switched off by means of covers
- Solid covers NIRO
- Shafts and cog-wheels are cured and ground
- Linear line
- Robust machine construction
- Horizontal spindle with the possibility of switch-off at vertical milling
- Hand wheels for X, Y, Z axes control
- Master engine with screw brake
- Four times laid milling head radially / axially
- Cooling plant
- This machine meets the European safety regulations CE
STANDARD EQUIPMENT:
- Cooling plant
- Machine lights
- Solid angle table
- Ball screws
- Linear line X/Y/Z
- Protection of the working surface
- Vertical milling head with swivelling and folding device
- Device for millings trapping
- Tool accuracy DIN 8615
- Warranty period 24 month
- Servicing implements
- Service instructions with the list of spare parts
MACHINE SPECIFICATIONS:
| WORKING SURFACE | ||
|---|---|---|
| Horizontal longitudinal feeding (X) | mm | 450 |
| Table up feed (Z) | mm | 400 |
| Horizontal surfacing feed (Y) | mm | 350 |
| Clamping surface of the vertical table | mm | 400 x 256 |
| Width of T-grooves | mm | 14 (H 8) |
| Distance / number of T-grooves | mm / pcs | 50 / 5 |
| Maximum weight of work piece | kg | 400 |
| Clamping surface of the solid angle table | mm | 800 x 400 |
| Width of T-grooves | mm | 14 (H 8) |
| Distance / number of T-grooves | mm / pcs | 50 / 8 |
| Maximum weight of work piece | kg | 300 |
| VERTICAL MILLING SPINDLE | ||
| Tool clamping | DIN 69871 ISO 40 | |
| Quill lift | mm | 80 |
| Mechanic rotation speed ratio | automatically | |
| Speed range | Speed / min | 60 - 4500 |
| SWIVEL FOLDING VERTICAL MILLING HEAD | ||
| Tool clamping | DIN 69871 ISO 40 | |
| Quill lift | mm | 80 |
| Mechanic rotation speed ratio | automatically | |
| Speed range | Speed / min | 60 - 4500 |
| Master engine power | kW | 5,5 |
| FEED DRIVES | ||
| Feed | fluent, automatic | |
| Feed range X,Y,Z | mm/min | 10-2000 |
| Fast feed X,Y/Z | mm/min | 5000/4000 |
| Tool clamping | Hand and hydraulic | |
